Atlas Copco Oil-Free air compressor ZT 315 VSD

ZR/ZT compressor includes internal piping.coolers, motor, lubrication and control system. The even integrates an iMD oriMDGadsorption dryer .Installation is fault-free, commissioning time is low and noextemal instrument air is required. You simply plug andrun.

Availability:

Quantity:



Inquire Add to Basket

Model:
ZT315VSD
Brand:
Atlas Copco
Code:
8414809090

Product Description

Place Of Origin	Wuxi City,Jiangsu Province
Video Factory Inspection	Video Factory Inspection
Machinery Test Report	Provided
Minimum Order Quantity	1
Packaging Details	Neutral Packaging Or Customized According To Customer Requirements

Type	Working pressure		Free air delivery			Noise level	Weight
Type		bar(e)	l/s	m³/min	cfm	dB(A)	kg	lb
ZT 315 VSD-8.6 bar(e)	Minimum	3.5	240 - 833	14.4 - 50.0	508 - 1765	78	6950	15322
	Effective	7	238 - 788	14.3 - 47.3	504 - 1670	78	6950	15322
	Maximum	8.6	237 - 735	14.2 - 44.1	502 - 1557	78	6950	15322
ZT 315 VSD-10.4 bar(e)	Minimum	6	216 - 763	13.0 - 45.8	458 - 1616	78	6950	15322
	Effective	9	214 - 725	12.9 - 43.5	454 - 1535	78	6950	15322
	Maximum	10.4	416 - 681	25.0 - 40.9	881 - 1444	78	6950	15322

Advantage

1.Highest reliability

For over 60 years Atlas Copco has pioneered thed evelopment of oil-free air technology. Resulting in thelargest range of air compressors and blowers within ourindustry, Through continuous research and development.we achieved a new milestone, setting the standard for airpu rity as the first manufacturer to be awarded lS0 8573-1CLASS 0 certification. CLASS0 certification means zero risk of oil contamination from our products.

2.100% oil-free compressed air

The IS0 8573-1 CLASS 0 certification means, zero risk ofour products contaminating the compressed air. This means we won't damage your company's hard-won professional reputation due to oil contamination from ouroil-free produ cts.

3.Maximum energy efficiency

The ZR/ZT's superior oil-free screw elements provide the optimum combination of high Free Air Delivery (FAD) with the lowest energy consumption.Ample sized cooling, lowpressure drops and an extremely efficient drive train resultin the highest compressor package efficiency.

4.Global presence - local service

Our aftermarket product portfolio is designed to add maximum value for our customers by ensuring the optimum availability and reliability of their compressed air equipment with the lowest possible operating costs.We deliver this complete service guarantee through our extensive service organization, maintaining our positionas leader in compressed air.
